Airmar TM260 50/200kHz, 1kW
Model:
Model
Quantity:
TM260 50/200kHz, 1kW
The TM260 comes with a rugged stainless-steel mounting bracket that is easy to install and has a streamlined shape. The performance of Airmar’s "1 kW, 260 family" of transducers is legendary. The combination of power and sensitivity has made this the high-performing transducer of choice with conventional fishfinders. Operating at 50 and 200 kHz, the narrow, 6° beam at 200 kHz provides excellent target resolution and crisp images of fish holding tight to wrecks and reefs. The 50 kHz is excellent at deep-water detection, and the wide, 19° beam yields broad coverage under the boat.
Features
- Depth and fast-response water-temperature sensing
- 1 kW of power
- Dual-frequency elements:
- 50 kHz with a 19° beam width for depth performance to 800 m (2600')
- 200 kHz with a 6° beam width for depth performance to 294 m (1000')
- Available with a diplexer for single-transmission-line fishfinders and without a diplexer for dual-transmission-line fishfinders
- Transom mount for installation on outboard or inboard/outboard powered boats
- Stainless steel kick-up bracket locks in the “up” position and will not damage the transom
- SEALCAST™, seamless, urethane housing for long life in the water
- Also available as bronze thru-hull (B260), stainless steel thru-hull (SS260), and in-hull (M260) mounts
- Patented Xducer ID® technology
TM260 50/200kHz, 1kW, w/ V2 Bracket, JRC/Simrad 7-Pin, DT
Specifications
- Brand: Airmar Technology
- Cable-Length: 10 m (33')
- Common Use: Leisure/Yachting, Fishing
- Connector: Simrad 7-Pin, JRC 7-Pin, Raytheon 7-Pin, Apelco 7-Pin
- Conventional Beam: 19°/7°
- Country of Origin: USA
- Display Brand: Apelco, Simrad, JRC, Raytheon
- Display Connector: 7
- Frequency: 50/200 kHz
- Frequency Band: 50/200 kHz
- Functions: Depth, Temperature
- Housing: Urethane/Stainless Bracket
- Material: Urethane
- Max Deadrise: Up to 28°
- Max Deadrise Angle: 28°
- Max Depth: Low frequency- 800 m (2600'), High frequency- 294 m (1000)
- Max Vessel LOA: 10 m (33') and above
- Mix and Match Series: 9-Pin 1000 Watt
- Model or Series: TM260
- Mounting Style: Transom
- Power Rating: 1 kW
- Product Family: Marine
- Sensor Connector: MM1
- Single or Dual Frequency: Conventional Dual Frequency
- Tilted Element: No
- Transom Angle: up to 28°
- Weight: 4 kg (8.9 lb.)
TM260 50/200kHz, 1kW, w/ V2 Bracket, Navico 9-Pin, DT
Specifications
- Brand: Airmar Technology
- Cable-Length: 10 m (33')
- Common Use: Leisure/Yachting, Fishing
- Connector: Simrad 9-Pin, Lowrance 9-Pin, Navico 9-Pin
- Conventional Beam: 19°/7°
- Country of Origin: USA
- Cross Reference: 000-13904-001
- Display Connector: 9N
- Frequency Band: 50/200 kHz
- Functions: Depth, Temperature
- Housing: Urethane/Stainless Bracket
- Material: Urethane
- Max Deadrise: Up to 28°
- Max Deadrise Angle: 28°
- Max Depth: Low frequency- 800 m (2600'), High frequency- 294 m (1000)
- Max Vessel LOA: 10 m (33') and above
- Mix and Match Series: 9-Pin 1000 Watt
- Mounting Style: Transom
- Power Rating: 1 kW
- Sensor Connector: MM1
- Single or Dual Frequency: Conventional Dual Frequency
- Tilted Element: No
- Transom Angle: up to 28°
- Weight: 4 kg (8.9 lb.)
