B265LH
Low & High Frequency
• Low– 42 kHz to 65 kHz
25° to 16° beamwidth
Maximum depth 3000 ft
• High–130 kHz to 210 kHz
10° to 6° beamwidth
Maximum depth 1000 ft
• 103 kHz of total bandwidth from
one transducer

B265LM
Low & Medium Frequency
• Low– 42 kHz to 65 kHz
25° to 16° beamwidth
Maximum depth 3000 ft
• Medium–85 kHz to 135 kHz
16° to 11° beamwidth
Maximum depth 1500 ft
• 73 kHz of total bandwidth
from one transducer

B275LHW
Low & High Wide Frequency
• Low– 42 kHz to 65 kHz
25° to 16° beamwidth
Maximum depth 3000 ft
• High–150 kHz to 250 kHz
25° constant beamwidth
Maximum depth 500 ft
• 123 kHz of total bandwidth from
one transducer

R109LH
Low & High Frequency
• Low–38 kHz to 75 kHz
19° to 10° port/starboard
10° to 5° fore-aft beam
Max. depth 6000 ft
• High–130 kHz to 210 kHz
8° to 4° beam
Max. depth 1500 ft
• 117 kHz of total bandwidth
from one transducer

R109LM
Low & Medium Frequency
• Low–38 kHz to 75 kHz
19° to 10° port/starboard
10° to 5° fore-aft beam
Max. depth 6000 ft
• Medium–80 kHz to 130 kHz
13° to 8° beam
Max. depth 3000 ft
• 87 kHz of total bandwidth
from one transducer

R109LHW
Low & High Wide Frequency
• Low–38 kHz to 75 kHz
19° to 10° port/starboard
10° to 5° fore-aft beam
Max. depth 6000 ft
• High–150 kHz to 250 kHz
25° constant beam
Max. depth 500 ft
• 137 kHz of total bandwidth
from one transducer

R509LH
Low & High Frequency
• Low–28 kHz to 60 kHz
23° to 9° port/starboard
11° to 5° fore-aft beamwidth
Maximum depth 10000 ft
• High–130 kHz to 210 kHz
8° to 4° beamwidth
Maximum depth 1500 ft
• 112 kHz of total bandwidth from
one transducer

R509LM
Low & Medium Frequency
• Low–28 kHz to 60 kHz
23° to 9° port/starboard
11° to 5° fore-aft beamwidth
Maximum depth 10000 ft
• Medium–80 kHz to 130 kHz
13° to 8° beamwidth
Maximum depth 3000 ft
• 82 kHz of total bandwidth
from one transducer

R509LHW
Low & High Wide Frequency
• Low–28 kHz to 60 kHz
23° to 9° port/starboard
11° to 5° fore-aft beamwidth
Maximum depth 10000 ft
• High–150 kHz to 250 kHz
25° constant beamwidth
Maximum depth 500 ft
• 132 kHz of total bandwidth from
one transducer
